PopPack battens, dimmable
POPPACK 11000-830 HFIX L1800
Article number: 96802001
EAN number: 5063618356025
Surface mounted LED luminaire 70.8W 10200lm 3,000 K
Luminous flux
10200 lm
Control
DALI-2, dimmable control gear
Correlated colour temperature
3000 K
Colour
White
Login to view your exclusive prices and stock availability
No account yet? Register and upgrade to access your individual pricing and stock info.
Delivery time on request
Technical Data
Electrical Properties
EEC
C
Luminaire input power
70.8 W
Power factor
0.95
Rated voltage
220 - 240 V
Driver
Driver 1: 1 x LC 90/150-400/330 o4a NF h16 EXC4
Safety Class
SC1
Control
DALI-2, dimmable control gear
Emergency included
No
Lum Data
Yes
Light Distribution
Light Source
LED
Luminous flux
10200 lm
Luminaire efficacy
144 lm/W
Correlated colour temperature
3000 K
Chromaticity tolerance (initial MacAdam)
3
Colour Rendering Index min.
80
Light Distribution
300mA
Physical Characteristics
Dimensions
1449x60x75 mm
Mounting type
Surface mounted
Length
1449 mm
Width
60 mm
Height
75 mm
Weight
1.952 kg
Colour
White
Impact strength
IK05
Degree of protection
IP20_IP40
Reflector Color
formed
Maintenance and Protection
Rated useful life (B10)
L80 100000 h 25 °C
overviewFeatures_indoor
Correlated colour temperature
3000 K
Luminous flux
10200 lm
Luminaire efficacy
144 lm/W
Luminaire input power
70.8 W
Degree of protection
IP20_IP40
Mounting type
Surface mounted
Norms and Standards
Certificates
Downloads
Accessories
PopPack battens, dimmable
96802001 POPPACK 11000-830 HFIX L1800
Batten LED luminaire. Electronic, DALI-2, dimmable control gear. Body: coated, formed steel, white (RAL9016). End caps: injection moulded polycarbonate. Diffuser: textured opal acrylic. Electrical connection via 2 x (3 x 2 x 2.5mm²) terminal block. Complete with 3000K LED.
Dimensions: 1449 x 60 x 75 mm
Luminaire luminous flux: 10200 lm
Luminaire efficacy: 144 lm/W
Weight: 2.76 kg
